Cummins generator sets are used for standby power, distributed generation and auxiliary power on mobile devices to meet customers’ multi-directional power needs. Widely used in office buildings, hospitals, factories, municipal, power plants, universities, recreational vehicles, yachts and home power supply and other fields.
+ Assembled by Cummins diesel engine and Leroy Somer/Stanford alternator.
+ Three filters as standard， fuel and water separator as optional.
+ Radiator and fan with safety guard.
+ Single bearing alternator IP 23， Insulation Class H.
+ Heavyduty steel as base frame and 8hrs operation base fuel tank.
+ Automatic controlpanel and 3poles circuit breaker， internal cable
+ 12V battery， battery wires.
+ Battery charger and float battery charger as standard supply scope.
+ Optional soundproof canopy，ATS，synchronization panel，trailers.
| Model | 1500 rmp/400v 3P 4W/50HZ/0.8PF | Engine Type | Dimensions(LxWxH)&Weight | ||||||
| Prime Power | Standby Power | Open Genset | Silent Genset | ||||||
| KVA | KW | KVA | KW | Dimension(mm) | weight(kg) | Dimension(mm) | weight(kg) | ||
| CCW-1250T5 | 1250 | 1000 | 1375 | 1100 | KTA50-G3 | 5000*2060*2500 | 9400 | 6058*2438*2591 | 15000 |
| CCW-1375T5 | 1375 | 1100 | 1650 | 1320 | KTA50-G8 | 5250*2110*2550 | 10600 | 12192*2438*2896 | 16200 |
| CCW-1475T5 | 1475 | 1180 | 1650 | 1320 | KTA50-GS8 | 5250*2110*2550 | 10600 | 12192*2438*2896 | 16200 |
